Color Coated Sheets
Star Roofing Solutions Pvt Ltd is one of the leading groups in the area mainly into Building Material & Textiles head quartered in panipat with a successful track record.
we are leading manufacturer and suppliers of a comprehensive range of color coated roofing sheets.
Our Mission is to provide clients across India with Color Coated Roofing Solutions for all type of Industrial building from concept planning through to completion with a highly skilled, Professional team. Star Roofing Solutions provide color coated sheets in various colors, sizes, heights, thickness and coating
Available Type & Finish
Pre-Painted Galvanized Steel (Zinc Coated) – PPGI
Pre-Painted Galvalume Steel (Zinc – Aluminum Alloy Coated) – PPGL
Bare Galvalume Steel (Zinc – Aluminum Alloy Coated)
Technical Product Specification
|
Pre-Painted Galvanized Steel |
Pre-Painted Galvalume / |
||||
| Thickness (TCT) | : | 0.30 mm – 0.80 mm | Thickness (TCT) | : | 0.30 mm – 0.80 mm |
| Metallic Coating | : | Z 120 (total on both sides) Higher or lower coating optional. |
Metallic Coating | : | Zinc-Aluminium Alloy Coating AZM150 Higher or Lower Coating optional. |
| Tensile Strength | : | 240 – 340 Mpa | Tensile Strength | : | 550 Mpa |
| Paint Coating | : | RMP / SMP/PVDF2 | Paint Coating | : | RMP / SMP/PVDF2 |
| Paint Thickness | : | 18 – 22 micron on Top & 5 – 8 micron primer on bottom | Paint Thickness | : | 18 – 22 micron on Top & 5 – 8 micron primer on bottom |
| Thickness Tolerance | : | As per ISI | Thickness Tolerance | : | As per ISI |
| Standard followed | : | IS 14246 / 277 / 513 | Standard followed | : | IS 277 / 513, ASTM1397 / A755 / A792 |
| Combination | : | 55% Al, 43.4% Zn & 1.5 – 1.6% Si | |||
Feature
Better insulation properties
Exert minimum pressure
Light in weight
Light in weight
Water resistant
Withstand tough weather
conditions
Superior loading capacity
Available in attractive color
Environment friendly
Economical
Low maintenance cost
Applications
Warehouses
Exhibition halls
Gymnasiums
Glasshouses
Household roofing
Commercial buildings
Industrial buildings
Shopping malls
